PRODUCT DESCRIPTION
Epoxy putty is a multi-purpose patching, sealing and mending compound. leaks,holes or cracks in materials can be repaired by the two part epoxy putty stick. When using metalworking tools, epoxy putty can be machined,drilled or tapped.
Typical Uses:
This product can be applied on substrate such as concrete and mainly used as intermediate coat for epoxy flooring system.
Application Guide
● Mixing:
Use the power mixer to mix the main paint evenly, and then as you stir it, you add the hardener until you get to mix well. Generally, if the temperature below 10 ℃, it needs 30 min induction time; if the temperature over 10℃, it needs 15 min induction time.
● Mixing Ratio:
Part A: Part B= 20: 5 (by weight).
● Thinner:
X-7 epoxy paint thinner.
● Airless Spray:
Nozzle tip: 0.021~0.025 inch.
Spray pressure: 15~18 MPa.
Thinner ratio: 0~10% (by weight of paint).
● Brush, Roller:
Recommended for small areas only. Must achieve required thickness.
Substrate temperature | 10 °C | 20 °C | 30 °C |
To touch (1mm) | 4h | 2h | 1h |
To handle (1mm) | 24h | 12h | 6h |
Min. recoating time | 16h | 8h | 4h |
Max. recoating time | 10h | 7h | 5h |
Pot life | 4h | 2h | 1h |
* Make sure no chalking and other contaminations before recoating. | |||
* Above data for reference only, actual drying time and recoating time is dependent on temperature, dry film thickness, ventilation condition. |
SURFACE TREATMENT
All surface to be coated shall be clean and dry. The surface shall be evaluated and treated according to ISO8504 standard.
Steel: Sanding to Sa2.5 (ISO8501-1:2007). It is acceptable to polish by power tools to meet at least St2.0(ISO8501-1:2007).
Steel coated with workshop primer: make sure workshop primer surface is clean, dry and undamaged.
Coated surface: applied on clean, dry and undamaged primer only.
Epoxy Sealing Primer: 30 µm (dry film thickness)
Epoxy Putty: 1*1mm (dry film thickness)
Epoxy Floor Paint: 1~2mm(dry film thickness)
SAFETY AND HEALTH
Please refer to MSDS before using this product. If you do not fully understand the restrictions, or cannot follow MSDS directions strictly, do not use this product. This volatile product is flammable. Keep this product away from flame or fire. Smoking is strictly prohibited in working area. Keep working area ventilated during application to make sure solvent vapor content is low in the air. PPE is necessary to avoid this product contacting with eyes or skin. More detailed safety tips are based on practical situation.
Please handle used paint barrel correctly to avoid any pollution.
Storage:
Store this product in shady, dry, and ventilated warehouse away from fire and heat. The shelf life is 12 months at room temperature.
Disclaimer:
All technical data given in this document is based on our knowledge achieved in lab and practice, it is not completely correct. Although we try to keep the validity of our advice, however we cannot predict the practical conditions that will affect paint quality. Herein, we cannot be responsible for the consequences of variations in such conditions, or for unforeseen conditions. We reserve the right to modify this document without informing in advance.
Packaging | Packing size | Packing weight |
Part A | 20L | 20 KG |
Part B | 6L | 5 KG |
