PRODUCT DESCRIPTION

This two-component product is mainly prepared by epoxy resin, ultra-fine zinc powder, and polyamide as curing agent. This product features:Antirust function,Good adhesion,Fast drying,Great resistance to oil, water, dust, stains and electrostatic,Compatible with most antirust paints and topcoats.

Typical Uses:

This heavy duty anticorrosion primer provides a cathodic protection layer in a wide range of industrial situations as:gas & oil storage tank,bridge,shipyard,galvanized workpiece,iron tower,boat,Offshore platform.

Anti-corrosive Polysiloxane Finish Paint for Concrete and Steel

这里可以自定义设置

Application Guide

● Mixing:

Mix part A and part B as 30:3 by weight. Slowly add part B into part A and ensure mixed completely.

● Mixing Ratio:

Ready to use

● Thinner:

X-7 Epoxy paint thinner ≤ 10 % w./w.

● Airless Spray:

Nozzle tip: 0.015-0.021 inch, minimum 150 bar/2100 psi.

Spray pressure: 18~28 MPa.

Thinner ratio: 5~15% (by weight of paint).

● Brush, Roller:

Recommended for small areas only.

Must achieve required thickness.

DRYING SCHEDULE

Substrate temperature	5 °C	23 °C	40 °C
To touch (h)	≤1.5h	≤0.5h	-
To handle(h)	24h	24h	-
To cure(h)	6h	4h	-
* Make sure no chalking and other contaminations before recoating.
* Above data for reference only, actual drying time and recoating time is dependent on temperature, dry film thickness, ventilation condition.

这里可以自定义设置

SURFACE TREATMENT

All surfaces to be coated shall be clean and dry. The surface shall be evaluated and treated according to ISO8504 standard.
Bare steel: sandblasting to Sa2.5(IOS8501-1:2007). For the non-soaking site, acceptable for power tool grinding, at least reach St2(IOS8501-1:2007).
Painted surface: only apply to clean, dry and intact compatible primer.

APPLICATION

Application conditions: Substrate temperature shall be at 3℃ higher than dew point, relative humidity less than 85%. Measurement of temperature and humidity should be close to substrate.

这里可以自定义设置

CLASSICAL COATING SYSTEM

Please inquiry JIANBANG Paint for specific coating solutions.

Epoxy Zinc Rich Primer : 2*40µm (dry film thickness)

Epoxy Mica Iron Oxide Intermediate Paint : 2*50µm (dry film thickness)

Acrylic Polyurethane Finish : 2*40µm (dry film thickness)

这里可以自定义设置

SAFETY AND HEALTH

Please refer to MSDS before using this product. If you do not fully understand the restrictions, or cannot follow MSDS directions strictly, do not use this product. This volatile product is flammable. Keep this product away from flame or fire. Smoking is strictly prohibited in working area. Keep working area ventilated during application to make sure solvent vapor content is low in the air. PPE is necessary to avoid this product contacting with eyes or skin. More detailed safety tips are based on practical situation.

Please handle used paint barrel correctly to avoid any pollution.

Storage:

Store this product in shady, dry, ventilated and away from heat sources warehouse. Storage temperature above 0℃, the shelf life is 12 months at room temperature. If exceeding shelf life, the products shall be tested before using.

Disclaimer:

All technical data given in this document is based on our knowledge achieved in lab and practice, it is not completely correct. Although we try to keep the validity of our advice, however we cannot predict the practical conditions that will affect paint quality. Herein, we cannot be responsible for the consequences of variations in such conditions, or for unforeseen conditions. We reserve the right to modify this document without informing in advance.
