    PRODUCT DESCRIPTION

    Reflective Acrylic Finish High Heat Clear Paint 6

    This two-component pack product is mainly prepared by special resin, heat insulating and anti-rust pigment and organic solvent. The coating can effectively insulate and reflect heat to achieve cooling effect. Typically used for LPG tank, tank trunk, organic solvent storage or similar applications, to keep constant temperature and reduce risks from high temperature. Besides, this paint has excellent anti-corrosion and decoration function.

    Typical Uses:

    This paint is mainly used as heat reflective topcoat or intermediate coat for applications, for instance, metal oil tank, chemical pipeline, refrigerator truck and LPG container. Meanwhile, it can be applied on concrete, wood or steel surface for heat insulation and cooling purpose.

    Reflective Acrylic Finish High Heat Clear Paint 7
    Reflective Acrylic Finish High Heat Clear Paint 8

    Application Guide

    Reflective Acrylic Finish High Heat Clear Paint 9

    ● Mixing:

    Use the power mixer to mix the main paint evenly, and then as you stir it, you add the hardener until you get to mix well. Generally, if the temperature below 10 ℃, it needs 30 min induction time; if the temperature over 10℃, it needs 15 min induction time.

    ● Airless Spray:

    Part A: Part B= 5:1 (by weight).

    ● Thinner:

    Exclusive thinner.

    ● Spray, brush, roller:

    Recommended must achieve required thickness.

    DRYING SCHEDULE

    Reflective Acrylic Finish High Heat Clear Paint 10

    Substrate temperature

    10 °C

    20 °C

    30 °C

    To touch (20μm)

    4h

    2h

    1h

    To handle (20μm)

    24h

    12h

    6h

    Min. recoating time

    16h

    8h

    4h

    Max. recoating time

    10d

    7d

    5h

    Pot Life

    4h

    2h

    1h

    * Make sure no chalking and other contaminations before recoating.

    * Above data for reference only, actual drying time and recoating time is dependent on temperature, dry film thickness, ventilation conditions.

    Reflective Acrylic Finish High Heat Clear Paint 11

    SURFACE TREATMENT

    Reflective Acrylic Finish High Heat Clear Paint 12

    A: A water-proof primer is necessary where long-term submersion in liquid or continuous exposure to moisture is a possibility.

    B: The coating can be applied direct non-metal surface. Surface should be clean and free of any oil.

    C: Rust, debris shall be removed if applied on metal surface.

    APPLICATION

    Reflective Acrylic Finish High Heat Clear Paint 13

    Application conditions: Substrate temperature shall be at 3 °C higher than dew point, relative humidity less than 85%. Measurement of temperature and humidity should be close to substrate.

    Reflective Acrylic Finish High Heat Clear Paint 14
    Reflective Acrylic Finish High Heat Clear Paint 15
    Reflective Acrylic Finish High Heat Clear Paint 16
    Reflective Acrylic Finish High Heat Clear Paint 17
    Reflective Acrylic Finish High Heat Clear Paint 18

    CLASSICAL COATING SYSTEM

    Reflective Acrylic Finish High Heat Clear Paint 19

    Please inquiry JIANBANG paint for specific coating solutions.

    Reflective Acrylic Finish High Heat Clear Paint 20

    Epoxy Sealing Primer: 2*40um (dry film thickness )

    Reflective Heat Insulation Coating: 2*50um (dry film thickness )

    SAFETY AND HEALTH

    Reflective Acrylic Finish High Heat Clear Paint 21

    Please refer to MSDS before using this product. If you do not fully understand the restrictions, or cannot follow MSDS directions strictly, do not use this product. This volatile product is flammable. Keep this product away from flame or fire. Smoking is strictly prohibited in working area. Keep working area ventilated during application to make sure solvent vapor content is low in the air. PPE is necessary to avoid this product contacting with eyes or skin. More detailed safety tips are based on practical situation.

    Please handle used paint barrel correctly to avoid any pollution.

    Storage:

    Store this product in shady, dry, and ventilated warehouse. Storage temperature should be above 0℃. The shelf life is 12 months at room temperature. If exceeding shelf life, the products shall be tested before using.

    Disclaimer:

    All technical data given in this document is based on our knowledge achieved in lab and practice, it is not completely correct. Although we try to keep the validity of our advice, however we cannot predict the practical conditions that will affect paint quality. Herein, we cannot be responsible for the consequences of variations in such conditions, or for unforeseen conditions. We reserve the right to modify this document without informing in advance.

    Reflective Acrylic Finish High Heat Clear Paint 22

    Packaging

    Packing size

    Packing weight

    Part A

    20L

    20 KG

    Part B

    5L

    4 KG
