Epoxy Coating For Metal Aliphatic Acrylic Polyurethane Coating
PRODUCT DESCRIPTION
● Good gloss and color retention
● Strong adhesion
● Fast drying
● Long durability
● Great resistance to salt & chemical corrosion, rust, impact
● Cures at temperatures down to -5 oC
● Etc
Typical Uses:
This product is typical used as finish paint for steel substrate as：
● Steel structure
● Ships
● Bridges
● Vehicle, machinery equipment
● Power plant
● Pulp mill and paper mills
● Traffic sign
● Chemical and petrochemical factory
PRODUCT SELLING POINT
● Nanotechnology, compact structure.
● Salt spray corrosion resistance ≥3000h,Resistance to aging≥5000h.
● 98% concentrated sulfuric acid for 1200h.
● Resistance to 30% hydrochloric acid for 1200h.
●Factory direct sale.
PRODUCT ADVANTAGES
PRODUCT APPLICATION GUIDE
| Mixing | Mix part A and part B as 20:4 by weight. Slowly add part B into part A and ensure mixed completely. |
| Thinner | BS52-10 exclusive thinner ≤ 10 % w./w. |
| Cleaner | BS52-10 exclusive thinner |
Application methods | Airless spray (recommended)：Nozzle tip: 0.017-0.023 inch, minimum 150 bar/2100 psi. Brush: recommended. Roller: recommended. |
MORE SPECIFIC COLORS PLEASE CONSULT US
DRYING SCHEDULE
Product | Thickness | |
Primer | Epoxy zinc rich primer | 50μm |
Midcoat | Epoxy mica iron oxide paint | 150μm |
| Topcoat | Acrylic polyurethane finish paint | 2*40μm |
*Color Variation:
PRODUCT SPECIFICATIONS
Color | Custom color (aluminum light) |
Gloss | High gloss |
Density | ~1.4kg/l |
| Hardness | Polyurethane curing agent |
| Solid Volume | ≥ 50 % |
Standard Film thickness | 60um dry film thickness (about 120um wet film thickness) |
Theoretical spreading rate | 9.6-11.6@ 50~75 µm dry film |
PRODUCT APPLICATION
TEST REPORT
Certificate
CUSTOMER EVALUATION
SHOW CASE
- 01
Dong Ying Olympics Sports Center
Products: Epoxy Sealing Agent + Epoxy Slurry Intermediate Layer+ Epoxy Self-leveling Floor Finish
———————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
- 02
PT.Conch North Sulawesi Cement
Products: Epoxy Sealing Agent + Epoxy Slurry Intermediate Layer+ Epoxy Self-leveling Floor Finish
———————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
03
PT Sgmw Motors Indonesia-lingyun Workshop
Product: Self-leveling Epoxy Floor Paint
