PRODUCT DESCRIPTION
This product is mainly used as exterior wall paint on substrate such as :
●Concrete
●Cement mortar
●Asbestos board Especially for maintenance of cracked walls (cracks ≤ 1.5mm)
PRODUCT SELLING POINT
● Nanotechnology, compact structure.
● The coating structure is designed independently.
● Import of 80% raw materials.
● Qualified for export of hazardous chemicals.
● Performance and color optimization customization.
PRODUCT ADVANTAGES
PRODUCT APPLICATION GUIDE
Mixing | Use the power mixer to mix the main paint evenly, and then as you stir it, you add the hardener until you get to mix well. |
Mixing Ratio | Part A: Part B= 5:1 (by weight) |
Thinner | Elastic exterior wall coating special thinner |
Airless spray | Nozzle tip:0.017~0.023 inch Spray pressure:15~18 MPa Thinner ratio:0~15% (by weight of paint) |
Brush、Roller | Recommended Must achieve required thickness |
MORE SPECIFIC COLORS PLEASE CONSULT US
DRYING SCHEDULE
Substrate Temperature | 10 ℃ | 20 ℃ | 30 ℃ |
To touch(30um) | 2h | 0.5h | 20min |
To handle(30um) | 24h | 24h | 18h |
Min. recoating time | 2h | 0.5h | 20min |
Max. recoating time | - | - | - |
Pot life | 4h | 2h | 1h |
* Make sure no chalking and other contaminations before recoating.
* Above data for reference only, actual drying time and recoating time is dependent on temperature, dry film thickness, ventilation conditions,humidity, mechanical strength, etc.
PRODUCT SPECIFICATIONS
Color | Customized color, matt |
Gloss | Glossy |
Density | 1.24Kg/L |
Hardener | Special curing agent |
Solid Volume | (40±2 )% |
Standard Film thickness | 60µm dry film thickness (about 150µm wet film thickness) |
Theoretical spreading rate | 6.06m²/Kg(60µm dry film thickness) |
Full cure | (23±2℃) 7d |
Flash point | 31℃ |
PRODUCT APPLICATION
Substrate temperature shall be at 3 ℃ higher than dew point, relative humidity less than 85%. Measurement of temperature and humidity should be close to substrate.
TEST REPORT
Certificate
CUSTOMER EVALUATION
SHOW CASE
Dong Ying Olympics Sports Center
Products: Epoxy Sealing Agent + Epoxy Slurry Intermediate Layer+ Epoxy Self-leveling Floor Finish
———————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
PT.Conch North Sulawesi Cement
Products: Epoxy Sealing Agent + Epoxy Slurry Intermediate Layer+ Epoxy Self-leveling Floor Finish
———————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
03
PT Sgmw Motors Indonesia-lingyun Workshop
Product: Self-leveling Epoxy Floor Paint
