PRODUCT DESCRIPTION

This product is composed of hybrid resin, acid-resistant filler, corrosion-resistant filler and organic solvent. Meanwhile, this paint has the thick film, good elasticity, good bending, small shrinkage, etc. Besides, it also has excellent resistance to salt fog, acid and alkali solution (including hydrofluoric acid, sulfuric acid, nitric acid, hydrochloric acid and so on). Furthermore, it is a high-performance long-acting anticorrosive coating which can withstand 220℃ for a long time, and at this high temperature, the performance of rapid cooling and rapid heating is good and the film to a variety of corrosive media has excellent resistance to permeability, water and chemical. What’s more, this coating also combines the strong adhesion, wear-resisting, high mechanical strength, long corrosion prevention period, etc.

Typical Uses:

This product is designed for the corrosion protection of the inner wall such as the desulfurization tower, the salt storage tank and the pressure tank in chemical and petrochemical enterprises.

这里可以自定义设置

PRODUCT SELLING POINT

● Repair rate 0, no downtime cost.

● The coating structure is designed independently.

● Performance and color optimization customization.

● Provide construction plan and construction service.

● The contract is guaranteed for 20 years.

PRODUCT ADVANTAGES

Repair rate 0,no downtime cost

Acceptance of all

Extend the presservative time by 2.5 times

Save 250% maintenance cost

这里可以自定义设置

PRODUCT APPLICATION GUIDE

Mixing	Use the power mixer to mix the main paint evenly, and then as you stir it, you add the hardener until you get to mix well.
Mixing Ratio	Part A: Part B = 20:5 (by weight)
Thinner	Desulfurization tower inner wall exclusive Anticorrosive paint thinner
Airless spray	Nozzle tip：0.017~0.023inch Spray pressure：15~18MPa Thinner ratio：0~15% (by weight of paint)
Brush、Roller	Recommended. Must achieve required thickness.

MORE SPECIFIC COLORS PLEASE CONSULT US

DRYING SCHEDULE

Substrate Temperature	10 ℃	20 ℃	30 ℃
To touch(50um)	4h	2h	1h
To handle(40um)	24h	12h	6h
Min. recoating time	16h	8h	4h
Max. recoating time	10d	7d	5d
Pot life	4h	2h	1h

* Make sure no chalking and other contaminations before recoating.

* Above data for reference only, actual drying time and recoating time is dependent on temperature, dry film thickness, ventilation conditions,humidity, mechanical strength, etc.

PRODUCT SPECIFICATIONS

Color	Zinc gray
Gloss	No Gloss
Density	-1.25Kg/L(after mixing)
Hardnes	Epoxy curing agent
Solid Volume	(45±2 )%
Standed Film thickness	100µm dry film thickness (about 222µm wet film thickness)
Theoretical spreading rate	3.6m²/Kg(100µm dry film thickness)
Full Cure	(23±2℃) 24h
Flash point	27℃

这里可以自定义设置

PRODUCT APPLICATION

Substrate temperature shall be at 3 ℃ higher than dew point, relative humidity less than 85%. Measurement of temperature and humidity should be close to substrate.
