Customized Road Marking Paint signing paint From China
PRODUCT DESCRIPTION
PRODUCT SELLING POINT
● Repair rate 0, no downtime cost.
● The coating structure is designed independently.
● Performance and color optimization customization.
● Provide construction plan and construction service.
.
● The contract is guaranteed for 20 years.
PRODUCT ADVANTAGES
PRODUCT APPLICATION GUIDE
| Mixing | Ready to use |
| Thinner | Acrylic paint thinner |
| Airless spray | Nozzle tip：0.017~0.023inch Spray pressure：15~18MPa Thinner ratio：0~15% (by weight of paint) |
Brush、Roller | Recommended for small areas only. Must achieve required thickness. |
MORE SPECIFIC COLORS PLEASE CONSULT US
DRYING SCHEDULE
| Substrate Temperature | 10 ℃ | 20 ℃ | 30 ℃ |
To touch(50um) | 2h | 1h | 30min |
To handle(50um) | 8h | 4h | 3h |
| Min. recoating time | 8h | 4h | 3h |
| Max. recoating time | - | - | - |
* Make sure no chalking and other contaminations before recoating.
* Above data for reference only, actual drying time and recoating time is dependent on temperature, dry film thickness, ventilation conditions.
PRODUCT SPECIFICATIONS
Color | Yellow, red, white |
Gloss | Glossy |
Density | -1.3Kg/L(after mixing) |
| Solid Volume | (50±2 )% |
| Film thickness | 100µm dry film thickness (about 200µm wet film thickness) |
| Theoretical spreading rate | 3.84m²/Kg(50µm dry film thickness) |
| Full cure | (23±2℃)24h |
| Flash point | 25℃ |
PRODUCT APPLICATION
Substrate temperature shall be at 3oC higher than dew point, relative humidity less than 85%. Measurement of temperature and humidity should be close to substrate.
TEST REPORT
Certificate
CUSTOMER EVALUATION
SHOW CASE
- 01
Dong Ying Olympics Sports Center
Products: Epoxy Sealing Agent + Epoxy Slurry Intermediate Layer+ Epoxy Self-leveling Floor Finish
———————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
- 02
PT.Conch North Sulawesi Cement
Products: Epoxy Sealing Agent + Epoxy Slurry Intermediate Layer+ Epoxy Self-leveling Floor Finish
———————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
03
PT Sgmw Motors Indonesia-lingyun Workshop
Product: Self-leveling Epoxy Floor Paint
