PRODUCT DESCRIPTION

This paint is based on phenolic resin and dry vegetable oil, filler drier and solvent. This paint has strong resistance to water, oil and weather. Besides, the paint also has good construction performance.

Typical Uses:

This product is suitable for indoor steel and iron equipment, components and wooden surface as protecting and decorating paint. Compared with other mixed paint, phenolic enamel has a much fuller film and can be used in construction, vehicles and mechanical equipment.

这里可以自定义设置

Application Guide

● Mixing:

Ready to use

● Mixing ratio:

Part A: Part B= 20:4 (by weight)

● Thinner:

Phenolic thinner

● Airless spray:

Nozzle tip: 0.017~0.023 inches
Spray pressure: 15~18Mpa

Thinner ratio: 5~15% (by weight of paint)

● Brush, Roller:

Recommended

Must achieve required thickness

DRYING SCHEDULE

Substrate temperature	10°C	20°C	30°C
To touch(30μm)	4h	2h	1h
To handle(30μm)	24h	12h	6h
Min. recoating time	16h	8h	4h
Max. recoating time	10d	7d	5d
Pot life	4h	2h	1h
* Make sure no chalking and other contaminations before recoating.
* Above data for reference only, actual drying time and recoating time is dependent on temperature, dry film thickness, ventilation conditions, humidity, mechanical strength,etc.

这里可以自定义设置

SURFACE TREATMENT

All surface to be coated shall be clean and dry. The surface shall be evaluated and treated according to ISO8504 standard.

For bare steel, it shall be sandblasted to reach Sa2.5(iso8501-1:2007) standard. Depending on the environment of the non-immersed part, grinding with power tools is acceptable but shall at least reach St2(iso8501-1:2007) standard.

For shop primed steel, the shop primer shall be clean, dry and approved.

For surface painted coatings, this product can apply only to clean, dry and good compatible primer.

APPLICATION

Application conditions: Substrate temperature shall be at 3 ℃higher than dew point, relative humidity less than 85%. Measurement of temperature and humidity should be close to substrate.

这里可以自定义设置

CLASSICAL COATING SYSTEM

Please inquiry JIANBANG Paint for specific coating solutions.

Classic Coating System

Epoxy Anti-rust Primer

2*40μm(dry film thickness)

Epoxy Intermediate Paint

2*50μm(dry film thickness)

Chlorinated Polyether Anti-corrosive Paint

2*30μm(dry film thickness)

这里可以自定义设置

SAFETY AND HEALTH

Please refer to MSDS before using this product. If you do not fully understand the restrictions, or cannot follow MSDS directions strictly, do not use this product. This volatile product is flammable. Keep this product away from flame or fire. Smoking is strictly prohibited in working area. Keep working area ventilated during application to make sure solvent vapor content is low in the air. PPE is necessary to avoid this product contacting with eyes or skin. More detailed safety tips are based on practical situation.
Please handle used paint barrel correctly to avoid any pollution.

Storage:

Store this product in shady, dry, and ventilated warehouse. The shelf life is 12 months at room temperature. If exceeding shelf life, the products shall be tested before using.

Disclaimer:

All technical data given in this document is based on our knowledge achieved in lab and practice, it is not completely correct. Although we try to keep the validity of our advice, however we cannot predict the practical conditions that will affect paint quality. Herein, we cannot be responsible for the consequences of variations in such conditions, or for unforeseen conditions. We reserve the right to modify this document without informing in advance.
