Epoxy Coal Tar Pitch Anti-corrosive Paint

这里可以自定义设置

PRODUCT DESCRIPTION

This product is based on aliphatic isocyanates and hydroxy resins, and has strong weather resistance. Meanwhile, the paint film is firm and glossy. Besides, it is a good choice for decoration as it won’t be powdered or get yellow easily. What’s more, its resistance to chemical and water is remarkable.

Typical Uses:

This product is commonly used as high-performance decorative coating for steel structure and aluminum alloy.

这里可以自定义设置

PRODUCT SELLING POINT

● Nanotechnology, compact structure.

● Salt spray corrosion resistance ≥3000h,Resistance to aging≥5000h.

● 98% concentrated sulfuric acid for 1200h.

● Resistance to 30% hydrochloric acid for 1200h.

●Factory direct sale.

PRODUCT ADVANTAGES

Repair rate 0, no downtime cost.Acceptance of all.

Extend the preservative time by 2.5 times.

Qualified for export of hazardous chemicals.

Performance and color optimization customization

这里可以自定义设置

PRODUCT APPLICATION GUIDE

Mixing	Use the power mixer to mix the main paint evenly, and then as you stir it, you add the hardener until you get to mix well.
Thinner	Polyurethane paint thinner
Mixing ratio	Part A: Part B = 20:4(by weight)
Airless spray	Nozzle tip: 0.017~0.025inches Spray pressure: 18~25Mpa Thinner ratio:0~15% (by weight of paint)
Brush, Roller	Recommended Must achieve required thickness.

MORE SPECIFIC COLORS PLEASE CONSULT US

DRYING SCHEDULE

Substrate Temperature	10 ℃	20 ℃	30 ℃
To touch(30um)	5h	2.5h	1.5h
To handle(30um)	24h	8h	4h
Min. recoating time	24h	8h	4h
Max. recoating time	-	-	-
Pot life	4h	2h	1h

* Make sure no chalking and other contaminations before recoating. If necessary, stucco thoroughly before coating.

* Above data for reference only, actual drying time and recoating time is dependent on temperature, dry film thickness, ventilation conditions, humidity, mechanical strength, etc.

PRODUCT SPECIFICATIONS

Color	Customized
Gloss	High gloss
Density	~1.25Kg/L(after mixing)
Hardness	Polyurethane paint thinner
Solid Volume	(50±2 )%
Standard Film thickness	60um dry film thickness (about 120um wet film thickness)
Theoretical spreading rate	6.67m²/Kg (60um dry film thickness)
Full cure	(23℃±2 )7d
Flash point	33℃

这里可以自定义设置

PRODUCT APPLICATION

Substrate temperature shall be at 3 ℃ higher than dew point, relative humidity less than 80%. Measurement of temperature and humidity should be close to substrate.
