YMS PAINT Over 20 years experience in the production of customized industrial paint coatings

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 1

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 2

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 3

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 4

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint

Theoretical Spreading Rate:

2.75m²/Kg (150um dry film thickness)

Full Cure:

(23±2℃ ) 7d

Flash Point:

27℃

Color:

Black, brown

Density:

~1.33Kg/L(after mixing)

Solid Volume:

(55±2 )%

Standard Film Thickness:

150um dry film thickness (about 230um wet film thickness)

Inquiry

Write a Review

PRODUCT DESCRIPTION

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 5

This product is based on aliphatic isocyanates and hydroxy resins, and has strong weather resistance. Meanwhile, the paint film is firm and glossy. Besides, it is a good choice for decoration as it won’t be powdered or get yellow easily. What’s more, its resistance to chemical and water is remarkable.

Typical Uses:

This product is commonly used as high-performance decorative coating for steel structure and aluminum alloy.

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 6

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 7

PRODUCT SELLING POINT

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 8

● Nanotechnology, compact structure.

● Salt spray corrosion resistance ≥3000h,Resistance to aging≥5000h.

● 98% concentrated sulfuric acid for 1200h.

● Resistance to 30% hydrochloric acid for 1200h.

●Factory direct sale.

PRODUCT ADVANTAGES

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 9

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 10

Repair rate 0, no downtime cost.Acceptance of all.

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 11

Extend the preservative time by 2.5 times.

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 12

Qualified for export of hazardous chemicals.

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 13

Performance and color optimization customization

PRODUCT APPLICATION GUIDE

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 14

Mixing	Use the power mixer to mix the main paint evenly, and then as you stir it, you add the hardener until you get to mix well.
Thinner	Polyurethane paint thinner
Mixing ratio	Part A: Part B = 20:4(by weight)
Airless spray	Nozzle tip: 0.017~0.025inches Spray pressure: 18~25Mpa Thinner ratio:0~15% (by weight of paint)
Brush, Roller	Recommended Must achieve required thickness.

MORE SPECIFIC COLORS PLEASE CONSULT US

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 15

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 16

DRYING SCHEDULE

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 17

Substrate Temperature	10 ℃	20 ℃	30 ℃
To touch(30um)	5h	2.5h	1.5h
To handle(30um)	24h	8h	4h
Min. recoating time	24h	8h	4h
Max. recoating time	-	-	-
Pot life	4h	2h	1h

* Make sure no chalking and other contaminations before recoating. If necessary, stucco thoroughly before coating.

* Above data for reference only, actual drying time and recoating time is dependent on temperature, dry film thickness, ventilation conditions, humidity, mechanical strength, etc.

PRODUCT SPECIFICATIONS

Color	Customized
Gloss	High gloss
Density	~1.25Kg/L(after mixing)
Hardness	Polyurethane paint thinner
Solid Volume	(50±2 )%
Standard Film thickness	60um dry film thickness (about 120um wet film thickness)
Theoretical spreading rate	6.67m²/Kg (60um dry film thickness)
Full cure	(23℃±2 )7d
Flash point	33℃

PRODUCT APPLICATION

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 18

Substrate temperature shall be at 3 ℃ higher than dew point, relative humidity less than 80%. Measurement of temperature and humidity should be close to substrate.

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 19

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 20

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 21

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 22

TEST REPORT

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 23

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 24

ISO-90012015-standard

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 25

RoHS

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 26

Special paint CE certificate

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 27

PU CE certificate

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 28

Floor paint CE certificate

Certificate

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 29

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 30

Occupational Health And Safety Management System OHSAS 18001 New

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 31

Environmental Management Syatem ISO14001 New

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 32

SRC

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 33

sgs1

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 34

SASO1

CUSTOMER EVALUATION

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 35

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 36

SHOW CASE

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 37

Dong Ying Olympics Sports Center

Products: Epoxy Sealing Agent + Epoxy Slurry Intermediate Layer+ Epoxy Self-leveling Floor Finish

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 38

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 39

———————————————————————————————————————————————————————————————————————————————————————————————————————————————————————

PT.Conch North Sulawesi Cement

Products: Epoxy Sealing Agent + Epoxy Slurry Intermediate Layer+ Epoxy Self-leveling Floor Finish

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 40

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 41

PT Sgmw Motors Indonesia-lingyun Workshop

Product: Self-leveling Epoxy Floor Paint

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 42

Professional Epoxy Coal Tar Pitch Anti-corrosive Paint Factory From China-YMS Paint 43

Get in touch with us

YMS Industrial paint suppliers core products, including anti corrosive paint, antirust paint, acid & alkali resisting paint, heat resisting paint, building & floor paint etc., help protect and extend substrate life for years.
