    PRODUCT DESCRIPTION

    Epoxy High Solid Volume Drinking Water Tank Finish 7

    This product is a two-component high solid volume product based on epoxy resin and polyamide curing agent. It is resistant to abrasion, impact, water and salt. Besides, this paint dries quickly and when the paint cures, the film is nontoxic and has no smell. This product, in accordance with Code for Health and Safety Assessment of Drinking Water Distribution Equipment and Protective Materials, has passed the test of Jiangsu Provincial Center for Disease Control and Prevention and proved to be nontoxic.

    Typical Uses:

    This product is widely used as anti-corrosive coating for ballast tank, drinking water tank, food tank, dry cargo tank and inner wall of water pipeline.

    Epoxy High Solid Volume Drinking Water Tank Finish 8
    Epoxy High Solid Volume Drinking Water Tank Finish 9

    Application Guide

    Epoxy High Solid Volume Drinking Water Tank Finish 10

    ● Mixing:

    Use the power mixer to mix the main paint evenly, and then as you stir it, you add the hardener until you get to mix well. Generally, if the temperature is below 10℃, it needs 30 min induction time; If the temperature is over 10℃, it needs 15 min induction time.

    ● Mixing Ratio:

    Part A: Part B= 20:5 (by weight)

    Thinner:

    Epoxy paint thinner

    ●Airless spray:

    Nozzle tip:0.018~0.028inches

    Spray pressure:18~25 MPa

    Thinner ratio:0~15% (by weight of paint)

    ● Brush、Roller:

    Recommended

    Must achieve required thickness.

    DRYING SCHEDULE

    Epoxy High Solid Volume Drinking Water Tank Finish 11

    Substrate temperature

    10 °C

    20 °C

    30 °C

    To touch (50um)

    4h

    2h

    1h

    To handle (50um)

    24h

    12h

    6h

    Min. recoating time

    24h

    24h

    12h

    Max. recoating time

    -

    -

    -

    Pot life

    6h

    4h

    2h

    * Make sure no chalking and other contaminations before recoating.

    *Above data for reference only, actual drying time and recoating time is dependent on temperature, dry film thickness, ventilation conditions, humidity, mechanical strength, etc.

    Epoxy High Solid Volume Drinking Water Tank Finish 12

    SURFACE TREATMENT

    Epoxy High Solid Volume Drinking Water Tank Finish 13

    All surface to be coated shall be clean and dry. The surface shall be evaluated and treated according to ISO8504 standard.

    For bare steel, it shall be sandblasted to reach Sa2.5(iso8501-1:2007) standard. Depending on the environment of the non-immersed part, grinding with power tools is acceptable but shall at least reach St2(iso8501-1:2007) standard.

    For shop primed steel, the shop primer shall be clean, dry and approved.

    For surface painted coatings, this product can apply only to clean, dry and good compatible primer.

    APPLICATION

    Epoxy High Solid Volume Drinking Water Tank Finish 14

    Application conditions: Substrate temperature shall be 3 ℃ higher than dew point, relative humidity less than 85%. Measurement of temperature and humidity should be close to substrate.

    Epoxy High Solid Volume Drinking Water Tank Finish 15
    Epoxy High Solid Volume Drinking Water Tank Finish 16
    Epoxy High Solid Volume Drinking Water Tank Finish 17
    Epoxy High Solid Volume Drinking Water Tank Finish 18
    Epoxy High Solid Volume Drinking Water Tank Finish 19
    Epoxy High Solid Volume Drinking Water Tank Finish 20
    Epoxy High Solid Volume Drinking Water Tank Finish 21
    Epoxy High Solid Volume Drinking Water Tank Finish 22
    Epoxy High Solid Volume Drinking Water Tank Finish 23
    Epoxy High Solid Volume Drinking Water Tank Finish 24
    Epoxy High Solid Volume Drinking Water Tank Finish 25

    CLASSICAL COATING SYSTEM

    Epoxy High Solid Volume Drinking Water Tank Finish 26

    Please inquiry JIANBANG Paint for specific coating solutions.

    Epoxy High Solid Volume Drinking Water Tank Finish 27
    Epoxy High Solid Volume Drinking Water Tank Finish 28

    Epoxy Sealing Primer: 1*30 µm (dry film thickness)

    Epoxy Putty: 1~2mm (dry film thickness)

    Anti-static Solvent-free Self-leveling Epoxy Floor Paint: 1*1mm(dry film thickness)

    SAFETY AND HEALTH

    Epoxy High Solid Volume Drinking Water Tank Finish 29

    Please refer to MSDS before using this product. If you do not fully understand the restrictions, or cannot follow MSDS directions strictly, do not use this product. This volatile product is flammable. Keep this product away from flame or fire. Smoking is strictly prohibited in working area. Keep working area ventilated during application to make sure solvent vapor content is low in the air. PPE is necessary to avoid this product contacting with eyes or skin. More detailed safety tips are based on practical situation.

    Please handle used paint barrel correctly to avoid any pollution.

    Storage:

    Store this product in shady, dry, and ventilated warehouse. Under room temperature, its shelf life is 12 months. If exceeding shelf life, the products shall be tested before using.

    Disclaimer:

    All technical data given in this document is based on our knowledge achieved in lab and practice, it is not completely correct. Although we try to keep the validity of our advice, however we cannot predict the practical conditions that will affect paint quality. Herein, we cannot be responsible for the consequences of variations in such conditions, or for unforeseen conditions. We reserve the right to modify this document without informing in advance.

    Epoxy High Solid Volume Drinking Water Tank Finish 30

    Packaging

    Packing size

    Packing weight

    Part A

    20L

    20 KG

    Part B

    6L

    5 KG
