    PRODUCT DESCRIPTION

    Epoxy Zinc Phosphate Anti-rust Paint 4

    This product is a two-component epoxy paint composed of epoxy resin and polyamide curing agent. Meanwhile, the paint contains zinc phosphate corrosion inhibitor pigment. It has excellent anti-corrosive performance and hard film. Besides, it also has strong impact resistance and wear resistance.

    Typical Uses:

    This product can be used as primer or intermediate paint for containers. Besides, it can also be used as intermediate paint or primer for new buildings and their maintenance in general atmosphere.
    Epoxy Zinc Phosphate Anti-rust Paint 5
    Epoxy Zinc Phosphate Anti-rust Paint 6

    PRODUCT SELLING POINT

    Epoxy Zinc Phosphate Anti-rust Paint 7

    ● Nanotechnology, compact structure.

    ● Salt spray corrosion resistance ≥3000h,Resistance to aging≥5000h.

    ● 98% concentrated sulfuric acid for 1200h.

    ● Resistance to 30% hydrochloric acid for 1200h.

    ●Factory direct sale.

    PRODUCT ADVANTAGES

    Epoxy Zinc Phosphate Anti-rust Paint 8

    Epoxy Zinc Phosphate Anti-rust Paint 9
    Repair rate 0, no downtime cost.Acceptance of all.
    Epoxy Zinc Phosphate Anti-rust Paint 10
    Extend the preservative time by 2.5 times.
    Epoxy Zinc Phosphate Anti-rust Paint 11
    Qualified for export of hazardous chemicals.
    Epoxy Zinc Phosphate Anti-rust Paint 12
    Performance and color optimization customization

    PRODUCT APPLICATION GUIDE

    Epoxy Zinc Phosphate Anti-rust Paint 13

    Mixing

    Use the power mixer to mix the main paint evenly, and then as you stir it, you add the hardener until you get to mix well. Generally speaking, if the temperature is below 10 , it needs 30 min induction time; if the temperature is over 10, it needs 15 min induction time.

    Thinner

    Epoxy paint thinner

    Mixing ratio

    Part A: Part B = 25:3 (by weight)

    Airless spray

    Nozzle tip: 0.018~0.027 inches

    Spray pressure: 15~18Mpa

    Thinner ratio: 5~15% (by weight of paint)


    Brush, Roller

    Recommended

    Must achieve required thickness.




    MORE SPECIFIC COLORS PLEASE CONSULT US

    Epoxy Zinc Phosphate Anti-rust Paint 14

    Epoxy Zinc Phosphate Anti-rust Paint 15

    DRYING SCHEDULE

    Epoxy Zinc Phosphate Anti-rust Paint 16


    Substrate Temperature

    10 ℃

    20 ℃

    30 ℃

    To touch(50um)

    2h

    1h

    30min

    To handle(50um)

    24h

    12h

    8h

    Min. recoating time

    6h

    6h

    4h

    Pot life6h4h2h

    * Make sure no chalking and other contaminations before recoating. If necessary, stucco thoroughly before coating.

    * Above data for reference only, actual drying time and recoating time is dependent on temperature, dry film thickness, ventilation conditions, humidity, mechanical strength, etc.



    PRODUCT SPECIFICATIONS

    Epoxy Zinc Phosphate Anti-rust Paint 17

    Color

    Gray, Iron red

    Gloss

    Flat

    Density

    ~1.42Kg/L(after mixing)

    HardnessEpoxy zinc phosphate curing agent

    Solid Volume

    (50±2 )%

    Standard Film thickness

    100um dry film thickness  (about 200um wet film thickness)

    Theoretical spreading rate

    3.52m²/Kg (100um dry film thickness)

    Full cure

    (23±2) 7d

    Flash point25℃

    PRODUCT APPLICATION

    Epoxy Zinc Phosphate Anti-rust Paint 18

    Substrate temperature shall be at 3 ℃ higher than dew point, relative humidity less than 85%. Measurement of temperature and humidity should be close to substrate.
