High-performance Aliphatic Polyurethane Finish Paint for Steel Structure1
PRODUCT DESCRIPTION
Typical Uses:
PRODUCT SELLING POINT
● Nanotechnology, compact structure.
● Salt spray corrosion resistance ≥3000h,Resistance to aging≥5000h.
● 98% concentrated sulfuric acid for 1200h.
● Resistance to 30% hydrochloric acid for 1200h.
●Factory direct sale.
PRODUCT ADVANTAGES
PRODUCT APPLICATION GUIDE
| Mixing | Use the power mixer to mix the main paint evenly, and then as you stir it, you add the hardener until you get to mix well. |
| Thinner | Polyurethane paint thinner |
| Mixing ratio | Part A: Part B = 20:4 (by weight) |
Airless spray | Nozzle tip: 0.017~0.025inches Spray pressure: 18~25Mpa Thinner ratio: 0~15% (by weight of paint) |
Brush, Roller | Recommended Must achieve required thickness. |
MORE SPECIFIC COLORS PLEASE CONSULT US
DRYING SCHEDULE
| Substrate Temperature | 10 ℃ | 20 ℃ | 30 ℃ |
To touch(30um) | 5h | 2.5h | 1.5h |
To handle(50um) | 24h | 8h | 4h |
Min. recoating time | 24h | 8h | 4h |
| Max. recoating time | - | - | - |
| Pot life | 4h | 2h | 1h |
* Make sure no chalking and other contaminations before recoating. If necessary, stucco thoroughly before coating.
* Above data for reference only, actual drying time and recoating time is dependent on temperature, dry film thickness, ventilation conditions, humidity, mechanical strength, etc.
PRODUCT SPECIFICATIONS
Color | Customized |
Gloss | High gloss |
Density | ~1.25Kg/L(after mixing) |
| Hardness | Aliphatic polyurethane curing agent |
Solid Volume | (50±2 )% |
Standard Film thickness | 60um dry film thickness (about 120um wet film thickness) |
Theoretical spreading rate | 6.67m²/Kg (60um dry film thickness) |
Full cure | (23±2℃) 7d |
| Flash point | 33℃ |
PRODUCT APPLICATION
Substrate temperature shall be at 3 ℃ higher than dew point, relative humidity less than 80%. Measurement of temperature and humidity should be close to substrate.
TEST REPORT
Certificate
CUSTOMER EVALUATION
SHOW CASE
- 01
Dong Ying Olympics Sports Center
Products: Epoxy Sealing Agent + Epoxy Slurry Intermediate Layer+ Epoxy Self-leveling Floor Finish
———————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
- 02
PT.Conch North Sulawesi Cement
Products: Epoxy Sealing Agent + Epoxy Slurry Intermediate Layer+ Epoxy Self-leveling Floor Finish
———————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
03
PT Sgmw Motors Indonesia-lingyun Workshop
Product: Self-leveling Epoxy Floor Paint
