PRODUCT DESCRIPTION

This product is composed of film-forming solution and conversion solution. Film-forming solution contains epoxy resin, butyral resin, anti-rust pigment, plasticizer auxiliaries and organic solvent while conversion solution contains phosphate, auxiliaries, and organic solvent. Significantly, this coating has excellently stable and long-lasting anti-corrosion effect because of the rust layer adhered to the metal surface.

Typical Uses:

This product is designed to directly apply on steel structure with rust (layer less than 30um). Meanwhile, it is used for the anti-corrosion protection of steel surface with simple rust removal.

这里可以自定义设置

Application Guide

● Mixing:

Use the power mixer to mix the main paint evenly, and then as you stir it, you add the hardener until you get to mix well.

● Thinner:

Exclusive thinner

● Airless Spray:

Nozzle tip: 0.025~0.031 inches

Spray pressure: 18~28Mpa

Thinner ratio: 5~15% (by weight of paint

● Brush, Roller:

Recommended

Must achieve required thickness

DRYING SCHEDULE

Substrate temperature	10 °C	20 °C	30 °C
To touch (40μm)	4h	2h	1h
To handle (40μm)	24h	12h	6h
Min. recoating time	10d	7d	5d
Max. recoating time	4h	2h	1h
* Make sure no chalking and other contaminations before recoating.
* Above data for reference only, actual drying time and recoating time is dependent on temperature, dry film thickness, ventilation condition.

这里可以自定义设置

SURFACE TREATMENT

The surface to be coated shall be clean, dry and free from contaminations. Also, the surface shall be evaluated and treated according to ISO8504 standard.

Bare steel: sandblasting to reach Sa2.5(IOS8501-1:2007). For the non-soaking site, acceptable for power tool grinding, at least reach St2(IOS8501-1:2007).

Painted surface: only apply to clean, dry and intact compatible primer.

APPLICATION

Application conditions: Substrate temperature shall be at 3 ℃ higher than dew point, relative humidity less than 85%. Measurement of temperature and humidity should be close to substrate.

这里可以自定义设置

CLASSICAL COATING SYSTEM

Please inquiry JIANBANG Paint for specific coating solutions.

Classic Coating System

Chlorosulfonated Polyethylene Anti-corrosion Primer------ 2*40µm (dry film thickness)

Chlorosulfonated Polyethylene Anti-corrosionIntermediatePrimer------2*80µm (dry film thickness)

Chlorosulfonated Polyethylene Anti-corrosion Finish------ 2*30µm (dry film thickness)

这里可以自定义设置

SAFETY AND HEALTH

Please refer to MSDS before using this product. If you do not fully understand the restrictions, or cannot follow MSDS directions strictly, do not use this product. This volatile product is flammable. Keep this product away from flame or fire. Smoking is strictly prohibited in working area. Keep working area ventilated during application to make sure solvent vapor content is low in the air. PPE is necessary to avoid this product contacting with eyes or skin. More detailed safety tips are based on practical situation.

Please handle used paint barrel correctly to avoid any pollution.

Storage:

Store this product in shady, dry, and ventilated warehouse. Under room temperature, its shelf life is 12 months. If exceeding shelf life, the products shall be tested before using.

Disclaimer:

All technical data given in this document is based on our knowledge achieved in lab and practice, it is not completely correct. Although we try to keep the validity of our advice, however we cannot predict the practical conditions that will affect paint quality. Herein, we cannot be responsible for the consequences of variations in such conditions, or for unforeseen conditions. We reserve the right to modify this document without informing in advance.
