    PRODUCT DESCRIPTION

    Industrial Functional Epoxy Floor Paint 6

    Epoxy floor coat is two parts amide cured epoxy that designed to give a chemical resistant, durable and hard wearing surface on a concrete floor. Also, it combines incredible hardness and bonding power to provide a heavy duty and to be used as topcoat. The main advantages of epoxy floor coat are immensely tough, fast curing, virtually odour free, chemical resistant, easy to clean and non-flammable.

    Typical Uses:

    This product is designed for a wide range of floors with various levels of mechanical and chemical exposure. It is also used to protect materials on substrate like concrete floors in workshops, factories, warehouse, garages and etc. The idea is for internal use only. It will cause yellowing and deterioration of the paint film over time when exposure to direct sunlight.
    Industrial Functional Epoxy Floor Paint 7
    Industrial Functional Epoxy Floor Paint 8

    PRODUCT SELLING POINT

    Industrial Functional Epoxy Floor Paint 9

    ● The epoxy floor paint is mainly prepared by epoxy resin, curing agent, dispersant and aggregates depend on requirements.

    ● Main advantages of this paint are great resistance of slippery, electrostatic, acid and alkali.

    ● Moreover, it also has good resistance to organic solvent, heavy load and abrasion.

    ● Besides, it combines incredible hardness and bonding power to provide a heavy duty and to be used as topcoat.

    PRODUCT ADVANTAGES

    Industrial Functional Epoxy Floor Paint 10

    Industrial Functional Epoxy Floor Paint 11
    Extend the service life by 2-3 years
    Industrial Functional Epoxy Floor Paint 12
    Resistance (chemical medium) 98% sulfuric acid, 30% hydrochloric acid carefree
    Industrial Functional Epoxy Floor Paint 13
    Five years bright as new, 5.99% Improve the yield of sensitive devices by 99%
    Industrial Functional Epoxy Floor Paint 14
    50% Avoid slips and increase safety by 50%

    PRODUCT PARAMETER

    Industrial Functional Epoxy Floor Paint 15

    Technical Details

    Color

    Choose from the color card

    Application Guide

    Mixing

    Stir the part A evenly by power mixer then add hardener until fully mixed. Generally, if the temperature below 10 ℃, it needs 30 min induction time; if the temperature over 10, it needs 15 min induction time.

    Gloss

    (35-75)Glossy

    Coverage

    5 to 8 sq. meters per litre

    Solid Volume

    50±2 %

    Mixing Ratio

    Part A: Part B= 20:5 (by weight)

    Film thickness

    DFT: 40-60µm (WFT: 80-120µm)

    Thinner

    X-7 Epoxy Paint Thinner

    Theoretical spreading rate

    12.5-8.3m²/L

    Airless Spray



    Nozzle tip: 0.021~0.025 inch

    Full cure

    7d

    Spray pressure: 15~18 MPa

    Flash Point

    25 ℃

    Thinner ratio: 0~10% (by weight of paint)

    Shelf Life

    12 months in sealed container

     Brush、Roller

    Recommended for small areas only. Must achieve required thickness.

    Ready for foot traffic

    After 24 hours

    MORE SPECIFIC COLORS PLEASE CONSULT US

    Industrial Functional Epoxy Floor Paint 16

    Industrial Functional Epoxy Floor Paint 17

    DRYING SCHEDULE

    Industrial Functional Epoxy Floor Paint 18

    Substrate Temperature

    10 ℃

    20 ℃

    30 ℃

    To touch

    4h

    2h

    1h

    To handle

    24h

    12h

    6h

    Min. recoating time

    16h

    8h

    4h

    Max. recoating time

    10d

    7d

    5d

    Pot life

    4h

    2h

    1h

    * Make sure no chalking and other contaminations before recoating

    * Above data for reference only, actual drying time and recoating time is dependent on temperature, dry film thickness, ventilation conditions


    PRODUCT SPECIFICATIONS

    Industrial Functional Epoxy Floor Paint 19

    Color

    Customized

    Gloss

    Glossy

    Density

     ~1.3 Kg/L(after mixing)

    Hardness

     Epoxy paint curing agent

    Solid volume

    (50±2) %

    Film thickness

    100&µm dry film thickness (about 200&µm wet film thickness)

    Theoretical spreading rate

    3.8m²/Kg (100&µm dry film thickness)

    Full Cure (23±2℃)

    7~15d

    Flash Point

    31℃

    PRODUCT APPLICATION

    Industrial Functional Epoxy Floor Paint 20

    Substrate temperature shall be at 3 ℃ higher than dew point, relative humidity less than 85%. Measurement of temperature and humidity should be close to substrate.

    Industrial Functional Epoxy Floor Paint 21
    Industrial Functional Epoxy Floor Paint 22
    Industrial Functional Epoxy Floor Paint 23
    Industrial Functional Epoxy Floor Paint 24
    Industrial Functional Epoxy Floor Paint 25
    Industrial Functional Epoxy Floor Paint 26

    TEST REPORT

    Industrial Functional Epoxy Floor Paint 27

    Industrial Functional Epoxy Floor Paint 28
    ISO-90012015-standard
    Industrial Functional Epoxy Floor Paint 29
    RoHS
    Industrial Functional Epoxy Floor Paint 30
    Special paint CE certificate
    Industrial Functional Epoxy Floor Paint 31
    PU CE certificate
    Industrial Functional Epoxy Floor Paint 32
    Floor paint CE certificate

    Certificate

    Industrial Functional Epoxy Floor Paint 33

    Industrial Functional Epoxy Floor Paint 34
    Occupational Health And Safety Management System OHSAS 18001 New
    Industrial Functional Epoxy Floor Paint 35
    Environmental Management Syatem ISO14001 New
    Industrial Functional Epoxy Floor Paint 36
    SRC
    Industrial Functional Epoxy Floor Paint 37
    sgs1
    Industrial Functional Epoxy Floor Paint 38
    SASO1

    CUSTOMER EVALUATION

    Industrial Functional Epoxy Floor Paint 39

    Industrial Functional Epoxy Floor Paint 40

    SHOW CASE

    Industrial Functional Epoxy Floor Paint 41

    1. 01

    Dong Ying Olympics Sports Center

    Products: Epoxy Sealing Agent + Epoxy Slurry Intermediate Layer+ Epoxy Self-leveling Floor Finish

    Industrial Functional Epoxy Floor Paint 42
    Industrial Functional Epoxy Floor Paint 43

    ———————————————————————————————————————————————————————————————————————————————————————————————————————————————————————

    1. 02

    PT.Conch North Sulawesi Cement

    Products: Epoxy Sealing Agent + Epoxy Slurry Intermediate Layer+ Epoxy Self-leveling Floor Finish

    Industrial Functional Epoxy Floor Paint 44
    Industrial Functional Epoxy Floor Paint 45

    ———————————————————————————————————————————————————————————————————————————————————————————————————————————————————————

    03

    PT Sgmw Motors Indonesia-lingyun Workshop

    Product: Self-leveling Epoxy Floor Paint

    Industrial Functional Epoxy Floor Paint 46
    Industrial Functional Epoxy Floor Paint 47
