Industrial Functional Epoxy Floor Paint
PRODUCT DESCRIPTION
Typical Uses:
PRODUCT SELLING POINT
● The epoxy floor paint is mainly prepared by epoxy resin, curing agent, dispersant and aggregates depend on requirements.
● Main advantages of this paint are great resistance of slippery, electrostatic, acid and alkali.
● Moreover, it also has good resistance to organic solvent, heavy load and abrasion.
● Besides, it combines incredible hardness and bonding power to provide a heavy duty and to be used as topcoat.
PRODUCT ADVANTAGES
PRODUCT PARAMETER
Technical Details | Color | Choose from the color card | Application Guide | Mixing | Stir the part A evenly by power mixer then add hardener until fully mixed. Generally, if the temperature below 10 ℃, it needs 30 min induction time; if the temperature over 10, it needs 15 min induction time. |
Gloss | (35-75)Glossy | ||||
Coverage | 5 to 8 sq. meters per litre | ||||
Solid Volume | 50±2 % | Mixing Ratio | Part A: Part B= 20:5 (by weight) | ||
Film thickness | DFT: 40-60µm (WFT: 80-120µm) | Thinner | X-7 Epoxy Paint Thinner | ||
Theoretical spreading rate | 12.5-8.3m²/L | Airless Spray
| Nozzle tip: 0.021~0.025 inch | ||
Full cure | 7d | Spray pressure: 15~18 MPa | |||
Flash Point | 25 ℃ | Thinner ratio: 0~10% (by weight of paint) | |||
Shelf Life | 12 months in sealed container | Brush、Roller | Recommended for small areas only. Must achieve required thickness. | ||
Ready for foot traffic | After 24 hours |
MORE SPECIFIC COLORS PLEASE CONSULT US
DRYING SCHEDULE
Substrate Temperature | 10 ℃ | 20 ℃ | 30 ℃ |
To touch | 4h | 2h | 1h |
To handle | 24h | 12h | 6h |
Min. recoating time | 16h | 8h | 4h |
Max. recoating time | 10d | 7d | 5d |
Pot life | 4h | 2h | 1h |
* Make sure no chalking and other contaminations before recoating
* Above data for reference only, actual drying time and recoating time is dependent on temperature, dry film thickness, ventilation conditions
PRODUCT SPECIFICATIONS
Color | Customized |
Gloss | Glossy |
Density | ~1.3 Kg/L(after mixing) |
Hardness | Epoxy paint curing agent |
Solid volume | (50±2) % |
Film thickness | 100&µm dry film thickness (about 200&µm wet film thickness) |
Theoretical spreading rate | 3.8m²/Kg (100&µm dry film thickness) |
Full Cure (23±2℃) | 7~15d |
Flash Point | 31℃ |
PRODUCT APPLICATION
Substrate temperature shall be at 3 ℃ higher than dew point, relative humidity less than 85%. Measurement of temperature and humidity should be close to substrate.
TEST REPORT
Certificate
CUSTOMER EVALUATION
SHOW CASE
- 01
Dong Ying Olympics Sports Center
Products: Epoxy Sealing Agent + Epoxy Slurry Intermediate Layer+ Epoxy Self-leveling Floor Finish
———————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
- 02
PT.Conch North Sulawesi Cement
Products: Epoxy Sealing Agent + Epoxy Slurry Intermediate Layer+ Epoxy Self-leveling Floor Finish
———————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
03
PT Sgmw Motors Indonesia-lingyun Workshop
Product: Self-leveling Epoxy Floor Paint
