    PRODUCT DESCRIPTION

    Inorganic Zinc-rich Primer 4

    This product is composed of alkyl silicate solution, ultrafine metal powder, color pigment, various additives, etc. With high content of zinc powder, its film has superior cathodic protection and great weather ability. Furthermore, the coating can withstand high temperature up to 400℃.

    Typical Uses:

    This product is widely designed as the anti-rust primer for the ferrous metal such as bridges, steel structure, iron tower and vehicles. Meanwhile, it can be used as the shop primer.
    Inorganic Zinc-rich Primer 5
    Inorganic Zinc-rich Primer 6

    PRODUCT SELLING POINT

    Inorganic Zinc-rich Primer 7

    ● The epoxy floor paint is mainly prepared by epoxy resin, curing agent, dispersant and aggregates depend on requirements.

    ● Main advantages of this paint are great resistance of slippery, electrostatic, acid and alkali.

    ● Moreover, it also has good resistance to organic solvent, heavy load and abrasion.

    ● Besides, it combines incredible hardness and bonding power to provide a heavy duty and to be used as topcoat.

    PRODUCT ADVANTAGES

    Inorganic Zinc-rich Primer 8

    Inorganic Zinc-rich Primer 9
    Extend the service life by 2-3 years
    Inorganic Zinc-rich Primer 10
    Resistance (chemical medium) 98% sulfuric acid, 30% hydrochloric acid carefree
    Inorganic Zinc-rich Primer 11
    Five years bright as new, 5.99% Improve the yield of sensitive devices by 99%
    Inorganic Zinc-rich Primer 12
    50% Avoid slips and increase safety by 50%

    PRODUCT PARAMETER

    Inorganic Zinc-rich Primer 13

    Mixingv

    Use the power mixer to mix the main paint evenly, and then as you stir it, you add the hardener until you get to mix well. Generally, if the temperature below 10 ℃, it needs 30 min induction time; if the temperature over 10℃, it needs 15 min induction time.

    Mixing ratio

    Part A: Part B = 24:6 (by weight)

    Thinner

    Inorganic exclusive thinner

    Airless spray

    Nozzle tip: 0.017~0.023inches
    Spray pressure: 15~18Mpa
    Thinner ratio: 5~15% (by weight of paint)

    Brush、Roller

    Recommended
    Must achieve required thickness

    MORE SPECIFIC COLORS PLEASE CONSULT US

    Inorganic Zinc-rich Primer 14

    Inorganic Zinc-rich Primer 15

    DRYING SCHEDULE

    Inorganic Zinc-rich Primer 16

    Substrate Temperature

    10 ℃

    20 ℃

    30 ℃

    To touch(30um)

    6h

    1h

    0.5h

    To handle(30um)

    24h

    8h

    4h

    Min. recoating time

    24h

    1h

    0.5h

    Pot life

    4h

    2h

    1h

    * Make sure no chalking and other contaminations before recoating

    * Above data for reference only, actual drying time and recoating time is dependent on temperature, dry film thickness, ventilation conditions


    PRODUCT SPECIFICATIONS

    Inorganic Zinc-rich Primer 17

    Color

    Gray

    Gloss

    Flat

    Density

    ~2.1Kg/L

    Solid Volume

    (45±2)%

    Standard Film thickness

    60um dry film thickness  (about 222um wet film thickness)

    Theoretical spreading rate

    3.57m²/Kg (100um dry film thickness)

    Flash Point

    35℃

    PRODUCT APPLICATION

    Inorganic Zinc-rich Primer 18

    Substrate temperature shall be at 3 ℃ higher than dew point, relative humidity less than 85%. Measurement of temperature and humidity should be close to substrate.
