PRODUCT DESCRIPTION
PRODUCT SELLING POINT
● Nanotechnology, compact structure.
● The coating structure is designed independently.
● Import of 80% raw materials.
● Qualified for export of hazardous chemicals.
● Performance and color optimization customization.
PRODUCT ADVANTAGES
PRODUCT APPLICATION GUIDE
Substrate Treatment: | All surface shall be clean, dry and free from any contaminations to achieve long lasting function |
Primed surfaces: | The primer surface should be dry and free from all contaminations. Areas of breakdown, damage etc., should be prepared to the specified standard, e.g. Sa2.5. |
Cleaner: | BS52-10 exclusive thinner |
Application methods: | Airless spray (recommended):Nozzle tip: 0.017-0.023 inch, minimum 150 bar/2100 psi |
Brush、Roller | Recommended |
MORE SPECIFIC COLORS PLEASE CONSULT US
DRYING SCHEDULE
Drying Time | 5 ℃ | 23℃ | 40 ℃ |
To touch/h | ≤16 | ≤1 | - |
To handle/h | ≤24 | ≤ 8 | - |
To cure/h | ≤24 | ≤8 | - |
* Data tested under controlled temperature and relative humidity below 85%.
PRODUCT SPECIFICATIONS
Color | Custom color |
Impact resistance, cm | 50 |
Adhesion, MPa | ≥ 6 |
Viscosity, s | ≥ 90 |
Fineness, µm | ≤30 |
Flexibility,mm | ≤2 |
Hardness | ≥ HB |
Pot life, h | 8 |
VOC, g/L | 180 |
PRODUCT APPLICATION
Apply in good weather. The substrate temperature shall be in the range of4- 40 oC, and at least 3 oC over dew point to avoid condensation. Also, ensure apply at humidity below 85%.
TEST REPORT
Certificate
CUSTOMER EVALUATION
SHOW CASE
Dong Ying Olympics Sports Center
Products: Epoxy Sealing Agent + Epoxy Slurry Intermediate Layer+ Epoxy Self-leveling Floor Finish
———————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
PT.Conch North Sulawesi Cement
Products: Epoxy Sealing Agent + Epoxy Slurry Intermediate Layer+ Epoxy Self-leveling Floor Finish
———————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
03
PT Sgmw Motors Indonesia-lingyun Workshop
Product: Self-leveling Epoxy Floor Paint
