Best Quality E06-500 Inorganic Heat-resistant Primer Factory
PRODUCT DESCRIPTION
PRODUCT SELLING POINT
● Repair rate 0, no downtime cost.
● The coating structure is designed independently.
● Performance and color optimization customization.
● Provide construction plan and construction service.
.
● The contract is guaranteed for 20 years.
PRODUCT ADVANTAGES
PRODUCT APPLICATION GUIDE
| Mixing | Use the power mixer to mix the main paint evenly, and then as you stir it, you add the hardener until you to mix the paint well. The mixture was cured for 30 minutes no less than 10 ℃, while 15minutes over 10 ℃. |
Mixing Ratio | Part A: Part B= 30:3 (by weight) |
| Thinner | Exclusive thinner for Inorganic Heat-resistant Paint |
| Airless spray | Nozzle tip：0.025~0.031inch Spray pressure：18~28MPa Thinner ratio：5~15% (by weight of paint) |
Brush、Roller | Recommended for small areas only. Must achieve required thickness. |
| Roller coater | Not recommended. |
MORE SPECIFIC COLORS PLEASE CONSULT US
DRYING SCHEDULE
| Substrate Temperature | 10 ℃ | 20 ℃ | 30 ℃ |
To touch(30um) | 1h | 0.5h | 0.2h |
To handle(30um) | 24h | 12h | 6h |
Min. recoating time | 8h | 4h | 2h |
Max. recoating time | 5d | 3d | 2d |
| Use time after mixing | 4h | 2h | 1h |
* Make sure no chalking and other contaminations before recoating.
* Above data for reference only, actual drying time and recoating time is dependent on temperature, dry film thickness, ventilation conditions,humidity, mechanical strength, etc.
PRODUCT SPECIFICATIONS
Color | Light Gray |
Gloss | Matt |
Density | -1.9Kg/L |
| Hardeness | Epoxy curing agent |
| Solid Volume | (45±2 )% |
| Standard Film thickness | 60µm dry film thickness (about 135µm wet film thickness) |
| Theoretical spreading rate | 3.94m²/Kg(80µm dry film thickness) |
| Full cure | (23±2℃) 24h |
| Flash point | 18℃ |
PRODUCT APPLICATION
Substrate temperature shall be 3 ℃ higher than dew point with relative humidity below 85%. Measurement of temperature and humidity should be conducted close to substrate.
TEST REPORT
Certificate
CUSTOMER EVALUATION
SHOW CASE
- 01
Dong Ying Olympics Sports Center
Products: Epoxy Sealing Agent + Epoxy Slurry Intermediate Layer+ Epoxy Self-leveling Floor Finish
———————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
- 02
PT.Conch North Sulawesi Cement
Products: Epoxy Sealing Agent + Epoxy Slurry Intermediate Layer+ Epoxy Self-leveling Floor Finish
———————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
03
PT Sgmw Motors Indonesia-lingyun Workshop
Product: Self-leveling Epoxy Floor Paint
